Dongfeng front four rear eight 8x4 oil tank truck

Vehicle parameters:

Run-known star brand SCS5311GYYD10 type Dongfeng front four rear eight tanker Main technical data
product name:	SCS5311GYYD10 type Dongfeng front four rear eight tanker	Dimensions (mm):	11680 * 2500 * 3750 (mm)
Product number:	SCS5311GYYD10	batch:	272
Chassis Type:	DFL1311A10	Compartment Dimensions (mm):	* * (Mm)
The total mass: (kg)	31000	Approach / departure angle (°)	28/10
Rated Quality: (kg)	16320,16255	Front / rear overhang (mm):	1460/2420
Curb weight: (kg)	14550	The maximum speed (km / h):	80
Axle load:	6500/6500/18000 (and biaxial loading)

Chassis parameters
Chassis Type:	DFL1311A10	Number of axes:	4
Wheelbase (mm):	1850 + 4350 + 1350, 1950 + 4250 + 1350, mm)	Front track (mm):	2040/2040
Front passenger:	2,3	Rear track (mm):	1860/1860
Number of tires:	12	Spring:	9/9 / 10,8 / 8 / 10,3 / 3 / 4,9 / 9 / -
Tire specifications:	11.00-20,11.00R20,295 / 80R22.5
other:	Optional ordinary cab, cab high roof top air horn for the option. Optional lamp exactly the same only different local cab appearance. The chassis optional muffler front, optional engine speed means the speed limit 80km / h.ABS manufacturer: Dongfeng electronic Technology Co., Ltd. brake systems; Model: 3631010-C2000.

Engine parameters
engine model	Engine manufacturers	Displacement (ml)	Power (kw)
ISDe270 40 ISLe270 40 ISLe292 40 ISLe315 40 ISC8.3-270E40A ISC8.3-292E40A dCi320-40 ISL9.5-315E40A YC6L280-42 YC6L310-42 ISL9.5-340E40A DDi75S270-40 DDi75S292-40 ISL9.5-292E40A	Dongfeng Cummins Engine Co., Ltd. Dongfeng Cummins Engine Co., Ltd. Dongfeng Cummins Engine Co., Ltd. Dongfeng Cummins Engine Co., Ltd. Dongfeng Cummins Engine Co., Ltd. Dongfeng Cummins Engine Co., Ltd. Dongfeng Commercial Vehicle Co., Ltd. Dongfeng Cummins Engine Co., Ltd. Guangxi Yuchai Machinery Co., Ltd. Guangxi Yuchai machinery Co., Ltd. Dongfeng Cummins engine Co., Ltd. Dongfeng commercial vehicle Dongfeng commercial Vehicle Co., Ltd. Dongfeng Cummins engine Co., Ltd.	6,700,890,089,008,900 8,300,830,011,120 9460 8424 8424 9,460,753,075,309,460	198 199 215 231.5 198,215,236,232,206 228,251,199,215,215
Emission Standards:		Fuel type:	Diesel fuel

Other information

Special Features:

1, the effective tank volume: 24.3 cubic meters, tank dimensions (length × long axis × short axis) (mm) 9000 × 2450 × 1640, 8800 × 2310 × 1600 transportation media: gasoline, density: 700 kg / cubic m class item number: class 3. 2, side, rear protective cold-formed steel / Q235, welding, protective cross section after high 100mm, cross-sectional width of 50mm, the lower edge of the high ground 530mm. 3. With the optional chassis cab; only the engine ISLe315 40, ISC8.3-270E40A, ISC8.3-292E40A, dCi320-40, ISL9.5-315E40A, YC6L280-42, YC6L310-42, ISL9.5-340E40A ; using only radial tires and front disc brakes, chassis exhaust pipe pre structure; installation of tachograph with a satellite positioning functions; ABS model / manufacturer: 3631010-C2000 / Dongfeng electronic Technology Co., Ltd. brake systems.

※ Note: these are just part of the product photos show Oh, want to know more about Hubei Yun force Dongfeng front four rear eight tanker pictures and detailed information about the dial hotline: 0722-7169251 8618872992009, also come to my company tours, Address: Hubei Suizhou economic Development Zone No. 77 centuryBoulevard, we welcome your presence!
